Description

Zebra ZT231 4-Inch Industrial Thermal Transfer Label Printer 203dpi with Wi-Fi [ZT23142-T0PC00FZ] is a versatile industrial barcode printer designed for warehousing, logistics, manufacturing, retail distribution and inventory management.
Combining fast printing speeds of up to 305mm per second (12 ips), thermal transfer and direct thermal printing capabilities, and built-in 802.11ac Wi-Fi, Ethernet, USB and Serial connectivity, the Zebra ZT231 delivers dependable label printing with flexible wired and wireless network integration.
A durable metal frame, convenient side-loading media design and 4.3-inch colour touchscreen make it suitable for demanding commercial environments.
- Zebra ZT231 Industrial Barcode Label Printer
- Exact Manufacturer Part Number: ZT23142-T0PC00FZ
- Thermal Transfer and Direct Thermal Printing
- 203dpi Print Resolution
- Maximum Print Speed: 305mm/sec (12 ips)
- Maximum Print Width: 104mm (4.09")
- Built-in Wi-Fi 802.11ac
- Built-in Ethernet 10/100, USB 2.0, USB Host and RS-232 Serial
- Bluetooth Low Energy (BTLE) for Supported Setup and Management
- 4.3" Full-Colour Resistive Touchscreen
- Supports Thermal Transfer Ribbons up to 450m
- Durable Industrial Construction with Metal Frame
- Standard Tear-Off Media Handling
- Ideal for Warehouse, Shipping, Product and Asset Labels
Technical Specifications
| Brand | Zebra |
| Series | ZT231 |
| MPN | ZT23142-T0PC00FZ |
| Printer Type | Industrial Barcode Label Printer |
| Print Methods | Thermal Transfer / Direct Thermal |
| Print Resolution | 203dpi / 8 dots per mm |
| Maximum Print Speed | 305mm/sec (12 ips) |
| Maximum Print Width | 104mm / 4.09" |
| Maximum Print Length | 3988mm at 203dpi |
| Media Width | 19.4mm – 114mm |
| Maximum Media Roll Diameter | 203mm with 76mm Core |
| Ribbon Capacity | Up to 450m |
| Ribbon Width | 51mm – 110mm |
| Ribbon Core | 25.4mm / 1" |
| Control Panel | 4.3" Colour Resistive Touchscreen |
| Wireless LAN | Built-in Wi-Fi 802.11ac |
| Wired Connectivity | USB 2.0, USB Host, RS-232 Serial, Ethernet 10/100 |
| Bluetooth | Bluetooth Low Energy (BTLE) |
| Printer Languages | ZPL, ZPL II, EPL, EPL2 |
| Memory | 256MB SDRAM / 256MB Flash |
| Media Sensors | Adjustable Transmissive and Reflective |
| Media Handling | Standard Tear-Off |
| Cutter / Peeler | Not Included |
| Printer Dimensions | 432 x 241 x 279mm (L x W x H) |
| Printer Net Weight | Approx. 9.1kg |
Built-in Wi-Fi and Ethernet Connectivity
Unlike the standard wired ZT231 configuration, the ZT23142-T0PC00FZ includes an integrated Wi-Fi 802.11ac wireless networking option, providing additional installation flexibility.
- Wi-Fi 802.11ac: Connect to compatible wireless business networks.
- Ethernet 10/100: Reliable wired network connectivity.
- USB 2.0: Direct connection to a computer or host.
- RS-232 Serial: Integration with compatible legacy equipment.
- USB Host: Supports compatible USB peripherals.
- Bluetooth Low Energy: Supported device configuration and management.
Important: Wi-Fi provides wireless network printing. Bluetooth Low Energy should not be confused with conventional Bluetooth wireless printing.
Fast 203dpi Industrial Barcode Printing
With print speeds of up to 305mm per second, the Zebra ZT231 is suitable for high-throughput label printing in warehouses, manufacturing facilities and distribution centres.
- Shipping and courier labels
- Warehouse inventory and location labels
- Carton and pallet identification
- Product and SKU barcode labels
- Manufacturing work-in-progress labels
- Asset tracking and equipment identification
- Retail and logistics labels
Thermal Transfer and Direct Thermal Printing
This ZT231 model supports both thermal transfer and direct thermal printing technologies.
- Thermal Transfer: Uses a compatible ribbon and label media for more durable printed labels.
- Direct Thermal: Uses compatible heat-sensitive labels without a ribbon for shipping and short-term identification.
For longer-lasting product and asset labels, select an appropriate thermal transfer ribbon and media combination based on the intended operating conditions.
Up to 450m Thermal Transfer Ribbon Capacity
The Zebra ZT231 supports compatible thermal transfer ribbons up to 450 metres long, helping reduce ribbon replacement frequency during high-volume label production.
- Maximum Ribbon Length: 450m
- Ribbon Width: 51mm – 110mm
- Ribbon Core: 25.4mm
- Compatible with selected wax, wax/resin and resin ribbons, depending on label material
Durable Industrial Design
The Zebra ZT231 combines a robust metal frame, convenient side-loading media path and 4.3-inch colour touchscreen for everyday commercial use.
- Industrial-grade construction
- Easy-access label and ribbon loading
- Large media viewing window
- Intuitive colour touchscreen controls
- Supports Zebra Print DNA software tools
- Suitable for integration with compatible inventory and warehouse systems
Zebra ZT231 Wired vs Wireless Model Comparison
| Feature | ZT23142-T0PC00FZ | ZT23142-T0P000FZ |
|---|---|---|
| Print Method | TT / DT | TT / DT |
| Print Resolution | 203dpi | 203dpi |
| Maximum Print Speed | 12 ips | 12 ips |
| Ethernet | Yes | Yes |
| USB / Serial | Yes | Yes |
| Wi-Fi 802.11ac | Included | Not Included |
| BTLE | Yes | Yes |
| Cutter | Not Included | Not Included |
Related Zebra ZT231 Industrial Printers
- Zebra ZT23142-T0P000FZ – 203dpi Thermal Transfer, Wired Network
- Zebra ZT23143-T0P000FZ – 300dpi Thermal Transfer, Wired Network
- Zebra ZT23142-T2P000FZ – 203dpi Thermal Transfer with Cutter and Catch Tray
- Zebra ZT23142-D0P000FZ – 203dpi Direct Thermal, Wired Network
What's Included?
- 1 x Zebra ZT231 203dpi Thermal Transfer Industrial Label Printer
- Built-in Wi-Fi 802.11ac Connectivity
- Manufacturer Part Number: ZT23142-T0PC00FZ
- Applicable Power Cord
- Manufacturer Documentation
Note: Label rolls, thermal transfer ribbons, optional cutter, peeler and other accessories are not included unless explicitly stated.
Frequently Asked Questions (FAQ)
Does ZT23142-T0PC00FZ include Wi-Fi?
Yes. This configuration includes built-in 802.11ac wireless networking.
Does it also have Ethernet?
Yes. It includes 10/100 Ethernet, USB 2.0, USB Host and RS-232 Serial connectivity.
Does the printer support thermal transfer and direct thermal printing?
Yes. It can use thermal transfer ribbons with compatible media or print directly on heat-sensitive labels without a ribbon.
How fast does it print?
Up to 305mm per second (12 inches per second).
What is the difference between T0PC00FZ and T0P000FZ?
The T0PC00FZ configuration includes Wi-Fi 802.11ac. The T0P000FZ is the standard wired configuration without built-in Wi-Fi.
Does Bluetooth Low Energy allow normal Bluetooth printing?
BTLE is intended for supported setup and management functions. It should not be treated as conventional Bluetooth wireless printing.
Does this model include a cutter?
No. This configuration uses standard tear-off media handling.
Product Description
The Zebra ZT231 Thermal Transfer Industrial Barcode Printer delivers reliable 203dpi printing for high-quality barcode labels. Equipped with USB and BTLE5 connectivity, it provides versatile integration into industrial workflows. Designed for durability and precision, it is ideal for warehouses, manufacturing, and logistics environments requiring consistent label production.
Product Specifications
-
Brand: Zebra
-
Part Number: ZT23142-T0PC00FZ
-
Colour: N/A
-
Printer Compatibility: N/A (Standalone thermal transfer industrial printer)
-
Function: Thermal transfer barcode label printing
Product Highlights – Bulleted List
-
203dpi industrial thermal transfer barcode printer
-
USB and BTLE5 connectivity for flexible integration
-
Durable design suitable for heavy-duty environments
-
Produces high-quality, accurate barcode labels
-
Ideal for warehouses, manufacturing, and logistics
Last Updated: 10 October 2026
