Specification
Type Desktop / Console Type
System Memory 2GB
HDD Optional: 80GB(Usable Space: 40GB)
Colour Capability Full Colour
Scanning Resolution 600 x 600dpi
Printing Resolution 600 x 600dpi ,1200 x 1200dpi (High resolution mode)
Halftone/Printable Colours 256 colour gradation for each colour (16,700,000 colour)
Warm-up Time 45 seconds or less (at 20C room temperature ) 35seconds or less (at 20C room temperature )
26 sec or less (After exiting low power mode:at 20C room temperature)
Original Paper Size
Platen: The maximum paper size is 215.9 x 355.6mm/Legal size 8.5 x 14″ for sheets and books.
Duplex Automatic Document Feeder : The maximum paper size is 215.9×355.6mm. The minimum size is 125.0×85.0mm(Simplex)/125.0×110.0mm(Duplex)
Output Paper Size Max. Paper Trays 1-4: A4, (215.9×355.6mm) Paper Tray 5 (MSI): A4
Min. Paper Trays 1-4: A6 , Monarch
Paper Tray 5 (MSI): Envelope (76.0×127.0mm), Monarch (98.0×190.0mm), Postcard (88.9×127.0mm)
Image loss Within 4mm for lead edge, Within 2mm for trail edge, Within 2mm for left/right side edges
Output Paper Weight Tray 1-4 60 – 216gsm
Tray 5 (MSI) 60 – 216gsm
First Copy Output Time A4SEF/BW or Colour mode (Platen) BW: 5.0sec / Colour: 7.0sec (Not in ACS)
A4SEF/BW or Colour mode (DADF)
BW: 7.0sec / Colour: 9.0sec (Not in ACS)
Reduction/Enlargement Size-to-Size 1:1±0.8%
Preset 1:0.50, 1:0.70, 1:0.81, 1:0.86, 1:1.15, 1:1.22, 1:1.41, 1:2.00
Variable 1:0.25~1:4.00 (1% increments)
Continuous Copy Speed A4 SEF (Simplex) BW: 45 cpm, Colour: 45 cpm
A4 SEF (Duplex) BW: 36 cpm, Colour: 36 cpm
Paper Tray Capacity Standard 700 sheets: 550 sheets (SrandardTray) +150 sheets (MSI)
Optional 1 Tray Module: 550 sheets, 2 Tray Module: 1,100 sheets
Maximum. 2,350 sheets: 550 sheets (Standard Tray) + 550 Sheets (1 Tray Module) +1,100 sheets (2 Tray Module) + 150 sheets (MSI)
Continuous Copy 999 copies
Output Tray Capacity 500 sheets (at 80gsm paper)
Dimensions Width 560 x Depth 536 x Hight 630mm (With Automatic Document Feeder)
Machine weight 56 kg (Mainframe + Automatic Document Feeder)
Space Requirement Width 1,090 x Depth 1,086mm (With MSI fully extended)
Print Function Type Built-in Type
Output Paper Size Same as Copy Function
Continuous Print Speed Same as the copy speed
Print Resolution Output Resolution 600 x 600dpi, 1,200 x 1,200dpi
Data Process Resolution Standard: 600x600dpi, High Quality: 600x600dpi,
High Resolution: 1,200×1,200dpi
PDL Standard PCL6, PCL5
Optional Adobe PostScript 3
Protocol Ethernet (Standard) TCP/IP (lpd, IPP, SMB, Port9100, ThinPrint, WSD)), Nobell Netware (IPX/SPX), NetBEUI(SMB), EtherTalk
USB2.0 (Optional) Compatible, Nibble, ECP
Standard
Windows 2000
Windows XP
Windows XP x64
Windows Server 2003
Windows Server 2003 x64
Windows Server 2008
Windows Server 2008 x64
Windows Server 2008 R2
Windows Vista
Windows Vista x64
Windows 7
Windows 7 x64
Mac OS X 10.5/10.6
Adobe PostScript 3 (Optional)
Windows 2000
Windows XP
Windows XP x64
Windows Server 2003
Windows Server 2003 x64
Windows Server 2008
Windows Server 2008 x64
Windows Server 2008 R2
Windows Vista
Windows Vista x64
Windows 7
Windows 7 x64
Mac OS 9.2.2
Mac OS X 10.3.9-10.4.11 (except 10.4.7)
Mac OS X 10.5/10.6
Fonts Standard(PCL) European 82 type face, Symbol 42 sets, Chinese font 1 (ShuSong) type face, Korean fonts 6 (Myungio, Gothic, Round Gothic, Graphic, Kungso, Saemul) type face
Optional PCL: Chinese fonts 4 type face Post Script: European 136 type face
Connectivity Standard Ethernet 1000BASE-T/100BASE-TX/10BASE-T, USB2.0*4
Scan Function Type Colour Scanner
Original Paper Size Same as the Copy function
Scanning Resolution Same as the copy speed
Scanning Halftone 10 bits input/8 bits output for each RGB colour
Scanning Speed Monochrome :45 sheets/min., Colour :45 sheets/min.
Connectivity Standard Ethernet 1000BASE-T/100BASE-TX/10BASE-T
Store to Folder (Scan to mailbox) Protocol TCP/IP (WebDAV, HTTP)
File Format Monochrome binary : TIFF, DocuWorks, PDF, XPS Grayscale : TIFF, JPEG, DocuWorks, PDF, XPS Full colour : TIFF, JPEG, DocuWorks, PDF, XPS
File Format Monochrome binary: TIFF, DocuWorks, PDF, XPSGrayscale: TIFF, JPEG, DocuWorks, PDF, XPS
Full Colour: TIFF, JPEG, DocuWorks, PDF, XPS
Scan to e-mail Protocol TCP/IP(SMTP)
File Format Monochrome binary: TIFF, DocuWorks, PDF, XPS Grayscale: TIFF, JPEG, DocuWorks, PDF, XPS
Full Colour: TIFF, JPEG, DocuWorks, PDF, XPS
Fax Function Send Document Size Maximum A4, Long document (Maximum. 600.0mm)
Recording Paper Size Maximum A4
Transmission Time 2 seconds or more but below 3 seconds
Transmission Mode ITU-T G3
Scanning Resolution Standard 8 x 3.85 lines/mm, 200 x 100dpi (7.9 x 3.9 dots/mm)
Fine 8 x 7.7 lines/mm, 200 x 200dpi (7.9 x 7.9 dots/mm)
Super Fine (400dpi) 400 x 400dpi (15.7 x 15.7 dots/mm)
Super Fine(600dpi) 600 x 600dpi (23.6 x 23.6 dots/mm)
Coding Method MH, MR, MMR, JBIG
Transmission Speed G3:33.6/31.2/28.8/26.4/24.0/21.6/19.2/16.8/14.4/12.0/9.6/7.2/4.8/2.4kbps
No. of Fax Lines Maximum. G3 -1 ports
Duplex Automatic Document Feeder
Type Duplex Automatic Document Feeder
Original Paper Size Maximum: 215.9×355.6mm / 215.9×600.0mm (in Fax mode) Minimum: 125.0mm x 85.0mm(in simplex mode) 125.0mm x 110.0mm(in duplex mode)
Outupt Paper Weight 38 – 128gsm (In duplex: 50 – 128gsm)
Paper Capacity 110 sheets
Feeding Speed Monochrome: Simplex 45 sheets/min , Duplex 27 sheets/min Colour : Simplex 45 sheets/min , Duplex 27 sheets/min
Dimensions/Weight Width 510 x Depth 405 x Height 105mm, 6kg
Duplex Output Unit Applicable Paper Size Same as the copy function
Paper Weight 60-163gsm
