Description
Brother ADS-4300N Scanner
Professional High Speed Desktop Scanner
- High-Performance, Professional Desktop Document Scanner
The ADS-4300N professional desktop document scanner has been designed to keep up with the fast pace of your business while simplifying operational processes.
The Brother ADS-4300N Professional Desktop Scanner is a compact solution with an 80-page auto document feeder (ADF). It features USB Type-B and Type-A ports, plus Ethernet connectivity, allowing you to send scans to your computer, to an optional USB memory stick, or to your network. By connecting to a wireless router, you can also link up to a wireless network and scan to AirPrint or Brother Mobile Connect mobile print services.
Digitize almost any document in up to 600 x 600 dpi optical scan resolution. Get single-side scans in up to 40 ppm and duplex scans in up to 80 ipm. An included software bundle lets you apply optimal image correction settings as well as create, edit, and convert scanned documents into different file formats/document types, including searchable PDFs.
- Kofax PaperPort SE with OCR for Windows
- Brother ScanEssentials for Windows
- Brother iPrint&Scan for Mac and Windows
- Brother Mobile Connect for iOS and Android
- Cerner certified
- Kofax VAR Elite / Kofax Express compatibility
- Paper jam sensor
General Specifications
Memory Capacity
|
Standard
|
ADS-4300N/ADS-4700W: 512 MB ADS-4900W: 1024 MB |
Power Source
|
AC: 100 - 240 V, 50/60 Hz
|
|
Touchscreen 4.3 in. (109.2 mm) TFT Color LCD |
||
Power Consumption *2
|
Scanning *3
|
ADS-4300N: Approximately 24 W ADS-4700W: Approximately 26 W ADS-4900W: Approximately 34 W |
Ready *4
|
ADS-4300N: Approximately 6.8 W ADS-4700W: Approximately 8.6 W ADS-4900W: Approximately 7.7 W |
|
Sleep
|
Approximately 1.7 W |
|
Power Down
|
Approximately 0.1 W |
|
Dimensions
(Typical outline view) |
Unit: in. (mm)
|
|
Weights
|
ADS-4300N: 5.8 lb (2.64 kg) ADS-4700W: 6.1 lb (2.75 kg) ADS-4900W: 7.4 lb (3.37 kg) |
|
Temperature
|
Operating
|
41°F to 95°F (5°C to 35°C) |
Storage
|
-4°F to 140°F (-20°C to 60°C) |
|
Humidity
|
Operating
|
20% to 80% |
Storage
|
10% to 90% |
|
ADF (Automatic Document Feeder)
|
ADS-4300N/ADS-4700W: Up to 80 sheets ADS-4900W: Up to 100 sheets (Paper: 20 lb (80 g/㎡) A4/Letter size) |
Document Specifications
Paper Type
|
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Business Card, Plastic Card
|
|
Document Size
|
Width
|
2.0 in. to 8.5 in. (50.8 mm to 215.9 mm)
|
Length
|
2.0 in. to 14.0 in. (50.8 mm to 355.6 mm)
|
Scanner Specifications
Color/Black
|
Yes/Yes |
|
TWAIN Compliant
|
Windows
|
Windows 7 (SP1) / Windows 8.1 / Windows 10 Windows Server 2012 / Windows Server 2012 R2 / Windows Server 2016 / Windows Server 2019 |
Mac
|
||
WIA Compliant
|
Windows
|
Windows 7 (SP1) / Windows 8.1 / Windows 10 |
ISIS Compliant
|
Windows
|
Windows 7 (SP1) / Windows 8.1 / Windows 10 |
Color Depth
|
Input
|
48 bit color processing |
Output
|
24 bit color processing |
|
Resolution
|
Interpolated
|
Up to 1200 x 1200 dpi |
Optical
|
Up to 600 x 600 dpi |
|
Scanning Width
|
Up to 8.5 in. (215.9 mm) |
|
Gray Scale
|
256 levels |
|
Max. Speed
|
For detailed specifications, visit www.brother.com. |
Direct Scan Feature (Scan to USB) Specifications
Compatible Media
|
USB flash drive *1 |
Interface
|
Interface USB 2.0 Hi Speed |
USB Mass Storage standard up to 128 GB
Supported formats: FAT12/FAT16/FAT32/exFAT
Interface Specifications
USB
|
USB 3.0 *1 Use a USB 3.0 cable (Standard A/Standard B) or USB 2.0 interface cable (Standard A/Standard B) that is no more than 6 feet (2.0 meters) long. |
LAN
|
Use an Ethernet UTP cable category 5 or later. |
Wireless LAN
(ADS-4700W/ADS-4900W) |
|
Your machine has a USB 3.0 interface. The machine can also be connected to a computer that has a USB 1.0/1.1/2.0 interface.
Third-party USB ports are not supported.
Network Specifications (ADS-4300N/ADS-4700W/ADS-4900W)
LAN
|
You can connect your machine to a network for Network Scanning. Also included is Brother BRAdmin Light Network Management software. |
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES) |
|
Setup Support Utility
|
WPS (ADS-4700W/ADS-4900W) WLAN Assistant (ADS-4700W/ADS-4900W) |
Supported Protocols and Security Features (ADS-4300N/ADS-4700W/ADS-4900W)
Ethernet
|
10BASE-T, 100BASE-TX |
Protocol (IPv4)
|
|
Protocol (IPv6)
|
RA, DNS Resolver, mDNS, LLMNR responder, HTTP/HTTPS server, ICMPv6, SNTP Client, Web Services (Scan) |
Network Security (Wired)
|
SMTP-AUTH, SSL/TLS (HTTPS, SMTP), TLS (SMTP), SNMP v3, 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) |
Network Security (Wireless)
(ADS-4700W/ADS-4900W) |
SSL/TLS(HTTPS) |
Network Security (Email)
|
SMTP-AUTH, SSL/TLS (SMTP) |
Wireless Certification
(ADS-4700W/ADS-4900W) |
WPA3™ - Enterprise, WPA3™ - Personal, Wi-Fi Protected Setup™, Wi-Fi Direct® |
The Brother ADS-4700W and ADS-4300N document scanners have a few notable differences:
-
Scanning Speed and Capacity: The ADS-4700W has a faster scanning speed at 40 pages per minute (ppm) and a higher capacity 80-sheet Automatic Document Feeder (ADF). The ADS-4300N offers a speed of 40 ppm as well, but its ADF capacity is typically lower at around 50 sheets.
-
Connectivity: The ADS-4700W supports wireless scanning and includes a larger, more user-friendly 4.3-inch color touchscreen for easier navigation and setup. The ADS-4300N, while offering network scanning capabilities, typically has a smaller display and less emphasis on wireless connectivity.
-
Software Integration: Both models support various software for optimizing workflow like Kofax and NewSoft, but the ADS-4700W might offer more robust integration options aimed at higher volume environments.
-
Design and Use Case: The ADS-4700W is designed for higher volume scanning environments requiring robust daily use, while the ADS-4300N is suitable for moderate scanning needs with slightly less emphasis on high-volume throughput.
These differences make the ADS-4700W more suitable for businesses with larger scanning needs and the ADS-4300N a good fit for small to medium-sized offices with regular but not excessively high-volume scanning requirements.
